One material for holding metal parts securely is plastic. The density of plastics is usually significantly lower than that of metals. Above all, the possibilities offered by 3D printing make this material a practical aid in the CT field. With plastic jaw chucks, round and cylindrical components can be clamped easily and quickly. Due to the very good density ratio to metal alloys, metal parts can be clamped quickly and easily and radiated with a very good contrast.
In contrast to conventional clamping systems, all components are made of plastic or carbon fiber metal parts are not used. This eliminates artifacts and other disturbing factors caused by metallic parts.
In combination with the buckling element 626170-0011-155 (not included), the parts can be brought into the machine at the best possible angle.
- Low weight
- Optimal contrast when radiating through metal parts
- No damage to sensitive components
- No tools required
- Product Type
Plastic jaw chuck with reversible jaws for internal and external clamping
- Outside diameter 70 mm
- Internal clamping (12.5 - 70 mm)
- External clamping (1 - 80 mm)
- Center bore 18 mm
Scope of delivery: 1 x plastic jaw with 3 reversing jaws set of fixing screws M4
